Camera

Image Sensor

1 / 2.5   "CMOS

Image Size

3840 × 2160

Electronic   Shutter

1 / 25 s ~ 1   / 100000 s

Iris Type

Fixed Iris

Min. Illumination

0.01 lux   @F1.2, AGC ON; 0 lux with IR

Lens

3.3 ~ 12 mm   @F1.4, horizontal field of view : 97.5° ~ 38.5°

Lens Mount

Φ14

Day &   Night

ICR

Wide Dynamic   Range

Digital WDR

BLC

Yes

HLC

Yes

Defogging

Yes

Digital NR

2D / 3D DNR

Angle   Adjustment

Any angle


Video Compression

H.265 MP; H.264   BP / MP / HP; MJPEG

Resolution

8MP ( 3840×2160 ), 1080P ( 1920×1080 ), 720P ( 1280×720 ), D1,   CIF, 480×240

Main Stream

60Hz : 8MP ( 1 ~ 30fps ) / 1080P ( 1 ~ 30fps ) / 720P ( 1 ~   30fps )

50Hz : 8MP ( 1 ~ 25fps ) / 1080P ( 1 ~ 25fps ) / 720P ( 1 ~   25fps )

Bit Rate

64 Kbps ~ 16   Mbps

Bit Rate Type

VBR / CBR

Quality

Five levels   under VBR; Freely adjustable under CBR

Image   Settings

ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic,   Sharpen, NR,etc. adjustable through client software or web browser

Audio Compression

G711A / U

ROI

Each ROI to   be configured separately

Interfaces

Network

RJ45 × 1, 10M   / 100M self-adaption

Audio

MIC IN × 1,   MIC OUT × 1

Video Output

CVBS video   output ( BNC × 1)

Storage Card

Support TF   card, up to 128GB

RS485

Yes

Alarm Input

1 CH

Alarm Output

1 CH

Functions

Remote Monitoring

IE   browsing,CMS remote control

Online   Connection

Support simultaneous monitoring for up   to 10 users; Support multi-stream real time transmission

Network   Protocol

TCP / IP,   UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP

Interface   Protocol

ONVIF,   GB-T/28181-2011

Storage

TF card local   storage, network remote storage

Smart Alarm

Motion alarm,   sensor alarm

Smart   Analysis

Object removal detection, line crossing detection and   intrusion detection, etc.

PTZ

RS485 × 1

PoE

Yes

IR Distance

30 ~ 50 m

Ingress   Protection

IP66

Others

Power Supply

DC12V / PoE

Power   Consumption

< 4.5W

IR   Consumption ON

< 8W

Operating   Environment

- 20 °C ~ 50   °C,10 % ~ 90 % relative humidity

Dimensions (   mm )

Φ109 × 284

Weight ( net   )

1112g

Installation

Wall   mounting, pendent mounting
