CHANNELs

16CH

VIDEO

INPUT SIGNAL

SD(960) / AHD,TVI(HD,FHD)/
3,4,5M, 4k15(TBD)

MAIN MONITOR

VGA/HD
(main/HD spot selectable)

SPOT OUT

2(CVBS)

LOOP THROUGH

YES

AUDIO

INPUT SIGNAL

16CH (10KOhm, 2.8Vpp)

OUTPUT SIGNAL

1CH (600Ohm, 2.8Vpp)

CODEC

G.711 ulaw

RECORDING

CODEC

H.264

REC. RATE

Up to 160FPS@ 5M
Up to 240FPS @ 4M
Up to 240FPS @ 3M
Up to 480FPS @ FHD

Up to 480FPS @ 2CIF

Up to 480FPS@ CIF

REC. RESOLUTION

CIF, 2CIF, D1, 960H, 720P, 1080P, 3M, 4M, 5M

ALARM I/O

ALARM INPUT

18CH(16CH+2CH), Pulled up to 5V via 10KOhm

ALARM OUT

8CH, RELAY(125VAC, 60VDC)

8CH, O.C. (Pulled up to 5V via 1KOhm)

STORAGE

INTERNAL HDD

Max 4EA w/ RAID5

EXTERNAL STORAGE

eSATA, NAS(FTP Server, for Backup)

INTERNAL ODD

1EA(DVD-RW) with HDD 4EA

INTERFACE

USB

3 ports(2Front + 1 Rear)

RS-485

2

RS-232

1

LAN

1 (LAN) + 1 (WAN) - 10/100/1000Mbps

REMOTE CONTROL

YES

ETC

SIGNAL SWITCH

NO

WATCHDOG

YES

COOLING FAN

Max 2x 80mm

POWER

POWER SUPPLY

DC12V, Adaptor, 7.5~10A, 100~200V AC, 50-60Hz

POWER CONSUMPTION

ENVIROMENT

TEMPERATURE
/ HUMINITY

0ºC ~ 40ºC (32ºF~104ºF) / 10 ~ 90% NC

CHASSIS

DIMENSION (mm)

2U(430 x 367 x 88.4)

NET WEIGHT(kg)

-

GROSS WEIGHT(kg)

-

CERTIFICATION

UL, CUL, FCC, CE

CE, FCC, c-Tick

MONITORING

DISPLAY RATE

480FPS/400FPS

DISPLAY RESOLUTION

4K/1080P/720P/VGA, Dual Display (Mirroring)

DISPLAY MODE

1,4,6,8,9,16

SEQUENCE

Programmable Sequence

DIGITAL ZOOM

YES

COVERT CAMERAS

YES

CAMERA COLOR
CONTROL

YES
(CONTRAST, COLOR,TINT, BRIGHTNESS)

PTZ CAMERA

YES

RECORD

SCHEDULE METHOD

DAILY/WEEKLY EACH HOUR

PROGRAMMABLE FOR CH

YES

MANUAL RECORDING

YES

POST-EVENT RECORDING

5/10/15/20/30/60/180 SEC

EVENT RECORDING

YES

PRE-EVENT RECORDING

0/1/2/3/4/5/10/15 SEC

PANIC RECORDING

YES

EVENT LOGGING

YES (MOTION,ALARM,PANIC,VLOSS)

SYSTEM LOGGING

YES (SYSTEM ON/OFF, TIME CHANGED,
HDD/EMAIL OPERATIONS, SYSYEM OPERATIONS)

SETUP LOGGING

YES (SETUP CHANGED)

REMOTE LOGGING

YES (WHO, IP ADDRESS, REMOTE OPERATIONS)

SEARCH
& PLAYBACK

DISPLAY MODE

1,4,9,16

PLAYBACK RATE

Same as Recording Rate

PLAYBACK SPEED

x1, x2, x4, x8, x16, x32, x64

SEARCH TYPE

CALENDER / EVENT / TIME / TUHMBNAIL

ARCHIVING

ARCHIVING DEVICES

USB Memory, FTP

REMOTE ARCHIVING

YES (WEB RA, VMS, FTP)

SNAPSHOT ARCHIVING

YES

DATA RESERVING

YES

RESERVED DATA LIST
MANAGEMENT

YES

BACKUP DATA FORMAT

AVI, RAW

WARTERMARK

YES

WARTERMARK
VARIFICATION

YES

ARCHIVED DATA
PLAYBACK

YES

NETWORK

MAX. CONNECTIONS

32 USERS

DHCP / DDNS

YES

TRANSMISSTION RATE

MAX 480 FPS

BANDWIDTH CONTROL

YES

WEB BROWER ACCESS

YES

REMOTE FUCNTION

REMOTE MONITORING / PLAYBACK
/ ARCHIVING / SETUP / PTZ CONTROL / HEALTH CHECK

VMS SUPPORT

YES

TWO-WAY AUDIO

YES

PC BASED
REMOTE AGENT

YES

SMART PHONE
APPLICATION

YES (iOS, Android)

WEB BASED
REMOTE AGENT

YES (WINDOWS®, LINUX, MAC OS/X®, ETC.)

SDK

YES (HTTP, RTSP Protocol Base)

AUTO ROUTER
PORT FORWARDING

YES

DUAL STREAMING

YES

FTP CLIENT

YES (For ARCHIVING)

E-MAIL

YES (SMTP CLIENT)

AUTHORITY CONTROL

ADMIN / MANAGER / USER

PROTOCOLS

RTP, RTSP, RTCP, SMTP, NTP, HTTP, FTP,
DDNS, DHCP, Upnp(Router Port Forwading)

TYPE

VIDEO LOSS EVENT / EVENT NOTIFICATION /
EVENT POPUP / MOTION DETECTION
/ MOTION SENSOR AREA

ETC

LANGUAGE

MULTI-LANGUAGE

KEYBOARD CONTROLLER

YES

OPERATING SYSTEM

LINUX®

FILE SYSTEM

ITX FILESYSTEM

DST SETUP

YES

DISK TEMPATURE
 CHECK

YES (DEPEND ON HDD SPEC)

DISK S.M.A.R.T CHECK

YES

AUTO DISK RECOVERY

YES

F/W UPGRADE

YES

SETUP IMPORT/EXPORT

YES

PTZ CONTROL

YES (PAN / TILT / ZOOM / FCOUS / IRIS / PRESET)
