Details
| Image Sensor | 1/2.9” 2.0MP SONY Exmor CMOS | |
| Effective Pixels | 1945(H) × 1097 (V) | |
| Resolution | Digital:1920×1080p(1080p/30fps) Analog:700TVL |
|
| S/N Ratio | ≥50dB (AGC Off) | |
| Min. IIIumination | COLOR：0. 1Lux@(F2.0，AGC ON) B&W：0.001Lux@(F2.0，AGC ON) |
|
| Scanning System | Progressive | |
| Video Output | HD-Analog: HD-CVI (TVI AHD) (1080P 、720P) Analog: 1Vp-p Composite Output (75Ω/BNC) |
|
| Day&Night | EXTERN,COLOR, B&W,AUTO | |
| White Balance | Auto | |
| OSD | English / Chinese | |
| Defog | OFF/ON | |
| WDR | OFF/LOW/MIDDLE/HIGH | |
| Privacy Mask | ON/OFF (16 Areas) | |
| Motion Detection | ON/OFF (4 Areas) | |
| IR LED | 4pcs IR Array | |
| Lens | 2.8-12mm Auto Focus | |
| IR Range | 50m | |
| Power Supply | DC12V±10% (AC24V Optional) | |
| Power Consumption | ＜7.5W | |
| Weight | 880g | |
| IP Rating | IP66 | |
| Storage Temperature | -20℃~60℃ | |
| Working Temperature/Humidity | -10℃ ~60℃，Humidity 90% or less (non-condensing) | |
