Electrical

Input Voltage

DC 12, AC 24V (±10%)

Power Consumption

Less than 700mA

Video

Image Pick-up Device

1/3" SONY 960H EX-View HAD CCD II

Total Pixels

1020(H) x 508(V)

Effective Pixels

976(H) x 494(V)

Scanning System

2:1 Interlace

Synchronization

Internal / Line lock

Scanning Frequency

Horizontal : 15,734KHz / Vertical : 59.94Hz

Horizontal Resolution

750TV lines

Min. Illumination

Color: 0.1 Lux(50IRE) / 0.06 Lux(15IRE)

B/W: 0.08 Lux(50IRE) / 0.006 Lux(15IRE)

S / N Ratio (Y signal)

52dB (AGC off)

Video Output

VBS 1.0Vp-p / 75

Lens

Zoom Ratio

4X

Focal Length

2.8 ~ 11.0mm (F1.2)

Max. Aperture Ratio

1 : 1.2 (Wide) ~ 2.2 (Tele)

Min. Object Distance

0.5m (1.64ft)

Angle Field of View

Horizontal : 102°(Wide) ~ 73°(Tele)

Vertical : 73°(Wide) ~ 53°(Tele)

PAN / TILT / ROTATE

Pan Range

0° ~ 360°

Tilt Range

0° ~ 95°

Rotate Range

0° ~ 360°

Operational

OSD

Multi-Language Support

Camera No. / ID

On / Off (Max. 256 No. 8ea ID / 1 Line)

Flickerless

On / Off (~ 1/200Ksec)

High Speed Shutter

1/60(1/50) ~ 1/20Ksec

Day & Night

Auto / Day / Night / Ext1,2

Auto Gain Control

On / Off (Max level setting)

White Balance

ATW/ AWC / Manual

2D DNR

Off / Low / Middle / High (Adaptive 2D

Defog Function / D-WDR

Off / Low / Mid / High

ETC. Function

Sharpness, Reverse(H), Shade

HLC / BLC

Off / Low / Mid / High

Motion Detection

4 /area (On / Off, Position, Sensitivity)

Privacy Masking

4 Area (On / Off, Color, Position)

Color Gain

Manual (0~20)

Gamma(r)

0.4 ~ 0.65

Environmental

Operating Temp/Humidity

Absolute: -10°C~ +50°C

Operating Humidity

30% ~ 80% RH

Storage Temp/Humidity

30% ~ 80% RH

Mechanical

IR LED

48 Smart LEDs

Ingress Protection

IP 66

Dimensions

254(W) x 140(H)mm

Weight

4.4 lbs. (2000g)
